| Mechanical |
|---|
| Pitch | 2.5 mm |
| Positions | up to 20 |
| Termination | IDC, crimp, soldering |
| Temperature range | -40°C ... +115°C |
|
| Electrical |
|---|
| Rated current | 5 A / 30°C
2.5 A / 70°C |
| Insulation resistance | >109 Ω |
| Contact resistance | < 10 m Ω |
| Test voltage | ≥ 1 kV |
| Rated voltage | 32 V |
| Approvals | UL |
|
| Materials |
|---|
| Housing | PC, glow wire resistant, GWT 750°C acc. to IEC 60335-1 |
| Contact | Socket IDC / Crimp: CuSn
Pin: CuZn |
| Contact finishing | Sn |
想了解更多连接器行业应用资讯，请点击以下链接——
/h-pr.html
东莞伟昌(TRNElectronic Technology)是集连接器产品研发、制造、对一体的专业伟昌连接器(TRNConnector)制造型企业，产品有环保无卤（SGS下载）0.6mm~30A线连接器( GWT灼热丝)、0.35mm板对板连接器、1.25~7.92mm线对线连接器、0.3mm FPC连接器、排针排母连接器、IDC刺式连接器、φ0.5~4.5设备端子、FFC排线、线束端子、IDC排线、SATA线电缆、汽车连接线及连接器模具（代工开发）研发制造。
伟昌连接器厂家从接插件、准确的、准确的汽车连接器、束线加工、Molex连接器、JST连接器等多类别为客户提供新品PCBA方案选型定制化服务。
伟昌电子关注最新动态从行业应用——LED灯、显示器、安防监控、家用、工业各领域自动化、医疗设备、数据存储传输出发，满足开发项目。长江连接器有限公司|CJT CONNECTORS|连接器|连接插件|电子连接器|连接器厂家
官网：/，产品咨询0769-89783288。
公司生产、板主要按无卤设备、UL安规等线严格执行ISO14000目标质量管理体系、线对板、线连接器、对线连接器、绝缘位移连接器、排针/母排/Sata、FPC连接器、FFC连接器、Adapter Board-In Connectors、ChainTerminal/Splices/Solderless、Terminals/SolderlessSplices、汽车连接器、防水连接器、电源连接器、LED连接器、LVDS连接器、NGFF/Mini-pci 连接器、Card Connectors、Batteryholder/Battery connector、Wiring-harness、PC Power Cable、Ribbon Cable Connectors、SATA Cable、RF Solutions、Automotive cable、Shunt Wires及Odm/Oemconnectors模具的研发、设计、生产与销售Cvilux连接器、JWT连接器。
产品主要替代TE、AMPHENOL、KET、YAZAKI、DELPHI、MOLEX、JAE、JST、HIROSE、PANASONIC、CVILUX、FCI、FOXCONN、UJU、JAM、STOCKO、SEIKO、HARWIN、KYOCERA、KEL、SAMTEC。
伟昌连接器产品全面防安新能源汽车、平板电脑、笔记本电脑、游戏机、微型仪器、监控头、家居、家居、智能、电视盒、LED照明电源、广告显示、DVD机智能手机、监控、车载医疗系统、自动识别、网络路由器、诊断表、血液分析、汽车导航、监控仪、车载设备、车载监测仪、伺服器、设备模块、电源模块、监控模块、摄像头模块模组等。
产品环保及安全规范符合ROHS2.0、无卤、REACH及UL安规等……
目前主要合作伙伴有华为、LENOVO、LOGITECH、HP、FOXCONN、LITEON、AOC、PRIMAX、BYD、CJT等……
| MKF13262-6-20-202 |
| MKF13263-6 |
| MKF13264-6 |
| MKF13265-6 |
| MKF13266-6 |
| MKF13267-6 |
| MKF13268-6 |
| MKF13269-6 |
| MKF13270-6 |
| MKF13271-6 |
| MKF13272-6 |
| MKF13273-6 |
| MKF13274-6 |
| MKF13275-6 |
| MKF13276-6 |
| MKF13277-6 |
| MKF13278-6 |
| MKF13279-6 |
| MKF13280-6 |
| MKS1651-6-0-202 |
| MKS1652-6-0-202 |
| MKS1653-6-0-303 |
| MKS1654-6-0-404 |
| MKS1655-6-0-505 |
| MKS1656-6-0-606 |
| MKS1657-6-0-707 |
| MKS1658-6-0-808 |
| MKS1659-6-0-909 |
| MKS1660-6-0-1010 |
| MKS1661-6-0-1111 |
| MKS1662-6-0-1212 |
| MKS1663-6-0-1313 |
| MKS1664-6-0-1414 |
| MKS1665-6-0-1515 |
| MKS1666-6-0-1616 |
| MKS1667-6-0-1717 |
| MKS1668-6-0-1818 |
| MKS1669-6-0-1919 |
| MKS1670-6-0-2020 |
| MKS1751-6-0-202 |
| MKS1752-6-0-202 |
| MKS1753-6-0-303 |
| MKS1754-6-0-404 |
| MKS1755-6-0-505 |
| MKS1756-6-0-606 |
| MKS1757-6-0-707 |
| MKS1758-6-0-808 |
| MKS1759-6-0-909 |
| MKS1760-6-0-1010 |
| MKS1761-6-0-1111 |
| MKS1762-6-0-1212 |
| MKS1763-6-0-1313 |
| MKS1764-6-0-1414 |
| MKS1765-6-0-1515 |
| MKS1766-6-0-1616 |
| MKS1767-6-0-1717 |
| MKS1768-6-0-1818 |
| MKS1769-6-0-1919 |
| MKS1770-6-0-2020 |
| MKS2651-6-0-202 |
| MKS2652-6-0-202 |
| MKS2653-6-0-303 |
| MKS2654-6-0-404 |
| MKS2655-6-0-505 |
| MKS2656-6-0-606 |
| MKS2657-6-0-707 |
| MKS2658-6-0-808 |
| MKS2659-6-0-909 |
| MKS2660-6-0-1010 |
| MKS2661-6-0-1111 |
| MKS2662-6-0-1212 |
| MKS2663-6-0-1313 |
| MKS2664-6-0-1414 |
| MKS2665-6-0-1515 |
| MKS2666-6-0-1616 |
| MKS2667-6-0-1717 |
| MKS2668-6-0-1818 |
| MKS2669-6-0-1919 |
| MKS2670-6-0-2020 |
| MKS2671-6-0-202 |
| MKS2672-6-0-202 |
| MKS2673-6-0-303 |
| MKS2674-6-0-404 |
| MKS2675-6-0-505 |
| MKS2676-6-0-606 |
| MKS2677-6-0-707 |
| MKS2678-6-0-808 |
| MKS2679-6-0-909 |
| MKS2680-6-0-1010 |
| MKS2681-6-0-1111 |
| MKS2682-6-0-1212 |
| MKS2683-6-0-1313 |
| MKS2684-6-0-1414 |
| MKS2685-6-0-1515 |
| MKS2686-6-0-1616 |
| MKS2687-6-0-1717 |
| MKS2688-6-0-1818 |
| MKS2689-6-0-1919 |
| MKS2690-6-0-2020 |
| MKS2751-6-0-202 |
| MKS2752-6-0-202 |
| MKS2753-6-0-303 |
| MKS2754-6-0-404 |
| MKS2755-6-0-505 |
| MKS2756-6-0-606 |
| MKS2757-6-0-707 |
| MKS2758-6-0-808 |
| MKS2759-6-0-909 |
| MKS2760-6-0-1010 |
| MKS2761-6-0-1111 |
| MKS2762-6-0-1212 |
| MKS2763-6-0-1313 |
| MKS2764-6-0-1414 |
| MKS2765-6-0-1515 |
| MKS2766-6-0-1616 |
| MKS2767-6-0-1717 |
| MKS2768-6-0-1818 |
| MKS2769-6-0-1919 |
| MKS2770-6-0-2020 |
| MKS2771-6-0-202 |
| MKS2772-6-0-202 |
| MKS2773-6-0-303 |
| MKS2774-6-0-404 |
| MKS2775-6-0-505 |
| MKS2776-6-0-606 |
| MKS2777-6-0-707 |
| MKS2778-6-0-808 |
| MKS2779-6-0-909 |
| MKS2780-6-0-1010 |
| MKS2781-6-0-1111 |
| MKS2782-6-0-1212 |
| MKS2783-6-0-1313 |
| MKS2784-6-0-1414 |
| MKS2785-6-0-1515 |
| MKS2786-6-0-1616 |
| MKS2787-6-0-1717 |
| MKS2788-6-0-1818 |
| MKS2789-6-0-1919 |
| MKS2790-6-0-2020 |
| MKS1851-6-0-202 |
| MKS1852-6-0-202 |
| MKS1853-6-0-303 |
| MKS1854-6-0-404 |
| MKS1855-6-0-505 |
| MKS1856-6-0-606 |
| MKS1857-6-0-707 |
| MKS1858-6-0-808 |
| MKS1859-6-0-909 |
| MKS1860-6-0-1010 |
| MKS1861-6-0-1111 |
| MKS1862-6-0-1212 |
| MKS1863-6-0-1313 |
| MKS1864-6-0-1414 |
| MKS1865-6-0-1515 |
| MKS1866-6-0-1616 |
| MKS1867-6-0-1717 |
| MKS1868-6-0-1818 |
| MKS1869-6-0-1919 |
| MKS1870-6-0-2020 |
| MKS1951-6-0-202 |
| MKS1952-6-0-202 |
| MKS1953-6-0-303 |
| MKS1954-6-0-404 |
| MKS1955-6-0-505 |
| MKS1956-6-0-606 |
| MKS1957-6-0-707 |
| MKS1958-6-0-808 |
| MKS1959-6-0-909 |
| MKS1960-6-0-1010 |
| MKS1961-6-0-1111 |
| MKS1962-6-0-1212 |
| MKS1963-6-0-1313 |
| MKS1964-6-0-1414 |
| MKS1965-6-0-1515 |
| MKS1966-6-0-1616 |
| MKS1967-6-0-1717 |
| MKS1968-6-0-1818 |
| MKS1969-6-0-1919 |
| MKS1970-6-0-2020 |
| MKS2851-6-0-202 |
| MKS2852-6-0-202 |
| MKS2853-6-0-303 |
| MKS2854-6-0-404 |
| MKS2855-6-0-505 |
| MKS2856-6-0-606 |
| MKS2857-6-0-707 |
| MKS2858-6-0-808 |
| MKS2859-6-0-909 |
| MKS2860-6-0-1010 |
| MKS2861-6-0-1111 |
| MKS2862-6-0-1212 |
| MKS2863-6-0-1313 |
| MKS2864-6-0-1414 |
| MKS2865-6-0-1515 |
| MKS2866-6-0-1616 |
| MKS2867-6-0-1717 |
| MKS2868-6-0-1818 |
| MKS2869-6-0-1919 |
| MKS2870-6-0-2020 |
| MKS2621-6-0-202 |
| MKS2622-6-0-202 |
| MKS2623-6-0-303 |
| MKS2624-6-0-404 |
| MKS2625-6-0-505 |
| MKS2626-6-0-606 |
| MKS2627-6-0-707 |
| MKS2628-6-0-808 |
| MKS2629-6-0-909 |
| MKS2630-6-0-1010 |
| MKS2631-6-0-1111 |
| MKS2632-6-0-1212 |
| MKS2633-6-0-1313 |
| MKS2634-6-0-1414 |
| MKS2635-6-0-1515 |
| MKS2636-6-0-1616 |
| MKS2637-6-0-1717 |
| MKS2638-6-0-1818 |
| MKS2639-6-0-1919 |
| MKS2640-6-0-2020 |
| MKS2951-6-0-202 |
| MKS2952-6-0-202 |
| MKS2953-6-0-303 |
| MKS2954-6-0-404 |
| MKS2955-6-0-505 |
| MKS2956-6-0-606 |
| MKS2957-6-0-707 |
| MKS2958-6-0-808 |
| MKS2959-6-0-909 |
| MKS2960-6-0-1010 |
| MKS2961-6-0-1111 |
| MKS2962-6-0-1212 |
| MKS2963-6-0-1313 |
| MKS2964-6-0-1414 |
| MKS2965-6-0-1515 |
| MKS2966-6-0-1616 |
| MKS2967-6-0-1717 |
| MKS2968-6-0-1818 |
| MKS2969-6-0-1919 |
| MKS2970-6-0-2020 |
| MKS11851-6-0-202 |
| MKS11852-6-0-202 |
| MKS11853-6-0-303 |
| MKS11854-6-0-404 |
| MKS11855-6-0-505 |
| MKS11856-6-0-606 |
| MKS11857-6-0-707 |
| MKS11858-6-0-808 |
| MKS11859-6-0-909 |
| MKS11860-6-0-1010 |
| MKS11861-6-0-1111 |
| MKS11862-6-0-1212 |
| MKS11863-6-0-1313 |
| MKS11864-6-0-1414 |
| MKS11865-6-0-1515 |
| MKS11866-6-0-1616 |
| MKS11867-6-0-1717 |
| MKS11868-6-0-1818 |
| MKS11869-6-0-1919 |
| MKS11870-6-0-2020 |
| MKS12851-6-0-202 |
| MKS12852-6-0-202 |
| MKS12853-6-0-303 |
| MKS12854-6-0-404 |
| MKS12855-6-0-505 |
| MKS12856-6-0-606 |
| MKS12857-6-0-707 |
| MKS12858-6-0-808 |
| MKS12859-6-0-909 |
| MKS12860-6-0-1010 |
| MKS12861-6-0-1111 |
| MKS12862-6-0-1212 |
| MKS12863-6-0-1313 |
| MKS12864-6-0-1414 |
| MKS12865-6-0-1515 |
| MKS12866-6-0-1616 |
| MKS12867-6-0-1717 |
| MKS12868-6-0-1818 |
| MKS12869-6-0-1919 |
| MKS12870-6-0-2020 |
